Description
WIKA pressure gauge, Type 213.53.100.
Case: stainless steel with crimped bezel
Type: 213.53-E
Specifications according to data sheet: PM 02.12
Measuring element: copper alloy
Diameter: 100 mm
Measuring range: -1 … + 9 bar
Scale or Special Scale: 2nd graduation psi
Process connection: G 1/2 B
Fitting position: eccentric rear
Collet / Caliper: Stainless Steel Front Collar
Accuracy class: Cl. 1.0
filling liquid: glycerine
Pressure Gauge Standard: International (EN837 standard)
color for 2nd scale: red RAL 3020
serial number on dial: serial number *. . . *
